General
This heater is a 1,500 W radiant patio heater,
using a halogen heating element, with light. Site
the heater outside or in a large open area, it is not
intended as a room heater, and well away from
any obstructions. It is shown assembled in Fig 1,
where the power switches are shown located
beneath the grille. One dark point may exist on
the surface of the heating element during the first
few minutes after it is turned on. This is normal
and will not affect the performance of the unit.
Assembly Instructions
Unpack the heater making sure that all the items
are present, that there are no components left in
the box and that the heater head is free from any
packing material. The heater must be handled
with care to avoid any damage.
Do not connect the heater to electrical supply
if any of the components or the power cord is
damaged in any way.
Method
Fix the base to the heater pole using the
3 pcs M8 * 25 mm screws provided. Tighten
screws by hand using the allen key provided,
see Fig 2.

Operation

Connect the power cord to a 13 amp supply
that is located in a safe dry area. The switches
on the heater are used to control the operation
of the heater and of the light on the top of the
heater. The switch marked (L) in Fig 1 controls
the light. The switch marked (E) in Fig 1 controls
the element. The unit must be securely grounded
during operation.
Although the heater is shower proof, do not
use when raining or in wet conditions. Always
disconnect the power cord from the electrical
supply when the patio heater is not in use.

Remote Control

This appliance is supplied with a remote that
can be used to control the light at the top of the
column. The remote can turn the light on/off,
change the brighness and change the colour,
see Fig 3.
A - Brightness Control
B - Turn Off / On
C - Colour Selection
D - Flash Mode
E - Strobe Mode
F - Fade Mode
G - Smooth Mode
Please remove the plastic battery insulation
sheet before using the remote. The battery is a
Lithium Cell type CR2025.
Care and Maintenance
The head of the heater is at a high temperature
during operation. Disconnect the
heater from the electrical supply and
wait until it cools before cleaning.
Clean the outside of the heater with
a damp cloth. Never use corrosive or
solvent cleaners or immerse in water.
Any maintenance or repairs including replacement
of the halogen tube should only be carried out
by a qualified electrician or by a recommended
service centre.
Recycling
For electrical products sold within the European
Community. At the end of the electrical products
useful life it should not be disposed of with
household waste. Please recycle where facilities
exist. Check with your Local Authority or retailer
for recycling advice in your country.
After Sales Service
Should you require after sales service, please
contact the retailer from whom the appliance
was purchased or contact the service number
relevant to your country on the warranty card.
Please do not return a faulty product to us in the
first instance as this may result in loss or damage
and delay in providing you with a satisfactory
service.
Please retain your receipt as proof of purchase.
Model Identifier(s):
Heat output
Nominal heat output
Minimum heat output (indicative)
Maximum continuous heat output
Auxiliary electricity Consumption
At nominal heat output
At minimum heat output
In standby mode
Type of heat output/ room temperature control
Single stage heat output and no room temperature control
Contact details
Clima 801LS
Pnom 1.5
Pmin 1.5
Pmax,c 1.5
elmax 0.0
elmin 0.0
elSB 0.0
GDHVI
Dunleer,
Co. Louth,
Ireland
kW
kW
kW
kW
kW
kW
Yes
