Maintenance; Troubleshooting Guide; Technical Specifications - Seg RR 1330 Bedienungsanleitung

Cleaning CD discs
If the music skips or does not play, the disc may need cleaning. Before playback,
wipe the disc from the center out with a clean cloth. After use, store the disc in its
case.
Problems
1. The player or
display does not
work properly.
2. The disc does
not play.
3. USB device is not
read.
4. Noise or
distorted sound
in radio mode.
CD/ USB
Compatible discs and files
USB port type
Radio
Tuning range
Antennas
Cassette
Recording system
Erasing system
Tape speed
General
Output power (RMS)
Power consumption
Speakers
Power source
Dimension
Weight
Note: Due to continuing improvements, the technical specifications are subject to
change without notice.

MAINTENANCE

TROUBLESHOOTING GUIDE

Recommendations
1.1 Set the FUNCTION switch to
again to other mode to turn on the unit.
1.2 Reset by unplugging the AC power cord for few
seconds, then plug it back in.
2.1 Place the disc with the label side facing up.
2.2 Ensure that the disc is free from scratches and
fingerprints.
2.3 Check that the discs/ file formats are compatible;
refer to "TECHNICAL SPECIFICATIONS".
2.4 Clean the disc.
3.1 Check that the USB device file system is in FAT or
FAT32 format.
3.2 Due to different formats, some models of USB
storage devices or MP3 players may not be read.
4.1 FM mode: extend and position the FM antenna to
achieve the best reception.
4.2 Set the MODE switch to FM MONO.

TECHNICAL SPECIFICATIONS

CD, CD-R/RW, CD-DA, MP3 and WMA
2.0
FM: 88 – 108 MHz
FM: telescopic antenna
AC bias
Magnetic erase
4.75 cm / sec.
2 x 1.2 W (AC power)
13 W
3" diameter, 8 Ohm impedance
AC 230V ~ 50Hz
DC 12V: 8 x 1.5V batteries UM2/"C" size
155 (H) x 288 (W) x 238 (D) mm
2.2 Kg
GB-8
position and set it
