Buttons and functions

Top
3
1. Air outlet
2. Folding handle
3. [ Turbo ] Fan speed setting low/high
4. On: LED indicator – indicates that
the automatic start timer function is
activated
5. [ Timer ] Enables automatic start/stop times
to be set
6. Off: LED indicator – indicates that
the automatic stop timer function is
activated
7. [ − ] Control used for setting the humidity
level and timer
8. Water full: LED indicator - lights when
the water reservoir is full, missing or not
fitted correctly
9. Display
5 7
4 6 8
2
1
9 10 11
10. [ + ] Control used for setting
the humidity level and timer
11. [ Mode ] Select from:
- Normal dehumidification, regulated
by the humidity level setting
(the water reservoir is subsequently
filled with water).
- Continuous dehumidification,
a humidity level setting cannot be
made
(the water runs out through
the connected drain hose).
12. Cont: LED indicator – lights when in
continuous dehumidification mode
13. LED indicator: Lights when
the dehumidifier is turned on.
14. [ Power ] On/Off
9
14
12
13
