Helios BL Montage- Und Betriebsvorschrift Seite 23

Installation and Operating Instructions
DIP settings for warning tones Alarm siren WH
Warning tone
DIP
profile
11111 Alternating
1
2 11110 Increasing
11101 Increasing
3
4 11100 Continuous tone
5 11011 Increasing
11010 Increasing
6
7 11001 Increasing
11000 Decreasing
8
10111 Alternating
9
10 10110 Intermittent
11 10101 Alternating
12 10100 Intermittent
13 10011 Intermittent
14 10010 Continuous tone
15 10001 Alternating
16 10000 Intermittent
17 01111 Intermittent
18 01110 Intermittent
19 01101 Continuous tone
20 01100 Alternating
21 01011 Intermittent
22 01010 Intermittent
23 01001 Increasing
24 01000 Increasing
25 00111 Intermittent
26 00110 Intermittent
27 00101 Intermittent
28 00100 Alternating
29 00011 Alternating
30 00010 Alternating
31 00001 Increasing
32 00000
Alternating
Signal generators BL, BLH, WH
Frequency
Tempo
Hz
800 and 970 2 Hz (250 ms - 250 ms)
800 to 970 7 Hz (7/s)
800 to 970 1 Hz (1/s)
2850 Continuous
2400 to 2850 7 Hz
2400 to 2850 1 Hz
3 s increasing, 0.5 s pause,
500 to 1200
then repeat
1200 to 500 1 Hz
2400 and 2850 2 Hz (250 ms - 250 ms)
970 0.5 Hz (1s on/1s off)
800 and 970 1Hz (500 ms - 500 ms)
2850 0.5 Hz (1s on/1s off)
970 0.8 Hz (250 ms on/1s off)
970 Continuous
554 and 440 100 ms - 400 ms
660 3.3 Hz (150 ms on/150 ms off)
660 0.28 Hz (1.8s on/1.8s off)
660 0.05 Hz (13s off/6.5 Hz on)
660 Continuous
554 and 440 0.5 Hz (1s on/1s off)
660 1 Hz (500 ms - 500 ms)
2850 4 Hz (150 ms on/100 ms off)
800 to 970 50 Hz
2400 to 2850 50 Hz
3x500 ms pulse, 1.5 s pause,
970
then repeat
3x500 ms pulse, 1.5 s pause,
800 to 970
then repeat
3x500 ms pulse, 1.5 s pause,
970 and 800
then repeat
800 and 970 2 Hz (250 ms-250 ms)
2 Hz (250 ms-250 ms)
990 and 650
(Symphonitones)
2 Hz (250 ms-250 ms)
510 and 610
(SquashniMicrotones)
300 to 1200 1 Hz
500 and 610 1 Hz (500 ms-500 ms)
10
WH 24V
Main application mA dB(A) dB(A)
FP fire 13
FP fire 12
FP fire 12
General 32
General 32
General 32
Netherlands fire
12
(NEN 2575)
Germany fire
15
(DIN 33 404)
General 31
PFEER alert 8
FP fire 12
General 17
General 5
PFEER toxic gas 14
France fire
17
(NFS 32-001)
Sweden (air raid) 6
Sweden (local warning) 7
Sweden (pre-mess) 6
Sweden (all clear) 10
Sweden (turnout) 16
Sweden general 6
Pelican crossing 27
FP fire 12
General 32
ISO8201 7
ISO8201 6
ISO8201 6
FP fire 12
FP fire 20
FP fire 16
General 14
16
FP fire
EN
EN54
DC -3
101 *
100 *
102 95
105 *
109 *
112 *
103 97
103 94
105 *
101 *
101 *
105 *
101 *
101 95
102 *
100 *
101 *
101 *
101 *
102 *
101 *
104 *
100 *
108 *
101 *
102 *
101 *
101 *
105 96
100 92
103 *
100 *
