In-Sight Micro series: DB15 I/O providing TRIGGER+, TRIGGER-, HS OUT 0, HS OUT 1 and
I/O Port
HS COMMON signals.
In-Sight 5000 series: DB15 I/O providing TRIGGER+, TRIGGER-, HS OUT 0 and HS OUT 1
signals, +24VDC and 24V Common.
In-Sight 7000 series: When connecting the In-Sight 7000 series vision system to the
CIO-MICRO or CIO-MICRO-CC I/O module, the I/O module's I/O port (DB15) is not supported.
Do not connect anything to this port.
Temperature Operating: 0°C to 45°C (32°F to 113°F)
Storage: -10°C to 65°C (14°F to 149°F)
