active fun TP30 Bedienungsanleitung Seite 10

TP30 Adventure Play House IN3337 Issue C 11 12:TP30 Adventure Play House IN3337 Issue C 11 12 13/11/2012 11:52 Page 10
4
M5 x
100mm
5
M5 x
100mm
MW2008
MW0169
4.5 x 50mm
10
x2
M5 x 100mm Woodscrew
x1
MW2008 (814mm)
x8
(294mm) 4.5 x 50mm Woodscrew
MW0169
4.5 x 50mm
x16
4.5 x 50mm
MW0169
4.5 x 50mm
x4
Adventure Play House
