Little Tikes 640728M Bedienungsanleitung

640728M
XIM640728 - 11/15
www.littletikes.com
www.littletikes.co.uk
www.littletikes.nl
www.littletikes.pl
ENGLISH
rock climber & slide
Ages: 2 - 6 years
Please save sales receipt for proof of purchase.
WArNiNG:
AdUlT AssemblY reQUired.
• Keep these instructions for future reference.
• Prior to assembly, this package contains small parts:
hardware which is a choking hazard and may contain
sharp edges and sharp points. Keep away from children
until assembled.
• To prevent serious injury, children must not use the
equipment until properly installed.
• Falls onto hard surfaces can result in head or other
serious injuries. Never place on concrete, asphalt, wood,
packed earth, grass or other hard surfaces. Carpet over
hard floors may not prevent injury. Always use protective
surfacing on the ground under and surrounding the
playground equipment according to the enclosed
"Consumer Information Sheet for Playground Surfacing
Materials." Maximum fall height protection up to 2 feet
(.6 m) required.
• Adult supervision required. Do not leave children
unattended.
• This product is intended for use by children ages
2 - 6 years.
• Maximum weight per child: 60 lbs. (27 kg). Limit 3
children.
• Shoes must be worn at all times.
• This product is intended for indoor or outdoor domestic
family use only.
• Observing the following statements and warnings
reduces the likelihood of serious or fatal injury.
• Place this product on level ground and at least 6' (2 m)
away from any object. Objects to be avoided include, but
are not limited to, fences, buildings, overhead branches,
laundry lines or electrical wires.
• It is recommended that the orientation of the assembled
product be such that direct sunlight is minimized on
surfaces intended for standing or sitting.
• Instruct children on proper use of this product, only
after properly placed, and not in a manner other than
intended.
• Do not allow children to climb on product when product
is wet.
• Instruct children not to attach items to the product that
are not specifically designed for use with the product
such as, but not limited to, jump ropes, clotheslines,
pet leashes, cables and chains, as they may cause a
strangulation hazard.
• Instruct children to remove their bike or other sports
helmet before playing on this product.
• Dress children appropriately: do not allow children to
wear loose-fitting clothing including ponchos, scarves
and garments with drawstrings. Well-fitting shoes must
be worn at all times.
• Protect your eyes. Always wear safety glasses when using
a hammer.
Adult assembly required / Le montage devra être effectué par un adulte /
Debe ser armado por un adulto
Tools required
(Not included):
Outils Requis
(Ne sont pas inclus):
Herramientas Requeridas
(No se incluye):
A
A. Side Castle Wall / Mur latéral du château /
Pared lateral del castillo
G
G. Bush Wall / Mur-buisson / Pared de arbustos
D
D. Ladder / Échelle / Escalera
N
N. Steering Wheel
Gouvernail
Volante
mAiNTeNANce
WARNING: Failure to perform periodic checks could
cause this product to overturn or cause a fall.
The following checks should be performed at the beginning
and end of each season and twice monthly during the usage
period:
• Reinstall any plastic parts, such as swing seats or any
other items that were removed for the cold season.
• Tighten all hardware.
• Lubricate all metallic moving parts at the beginning
of the play season and twice per month during
the play season.
• Check all protective coverings on bolts, pipes,
edges, and corners. Replace if they are loose,
cracked, or missing.
1
7 / " (1.11 cm) socket
16
Clé à douille de 1,11 cm
7
Llave tubular de 1,11 cm ( / ")
16
3 7
/ " & / " (.75 & 1.11 cm) socket #2 phillips extension
8 16
Clé à douille de ,75 & 1,11 cm Extension pour tournevis cruciforme n° 2
Llave tubular de ,75 & 1,11 cm ( 3 / 8 & 7 / ") Extensión Phillips nº 2
16
C
H
H. Slide / Toboggan / Tobogán
F
F. Log Threshold
Marchepied de rondins
Umbral de leño
O - 2
O - 1
O-1 O-2
Bolt Hub Pin
. .
Boulon Goujon de moyeu
Perno
Clavija de cubo
• Check all moving parts including swing seats,
ropes, cables, and chains for wear, rust, or other
deterioration. Replace if any of these conditions exist.
• Check metal parts for rust. If found, sand and
repaint using a nonlead-based paint meeting the
requirements of 16 CFR 1303.
• Rake and check depth of loose fill protective surfacing
materials to prevent compaction and to maintain
appropriate depth. Replace as necessary.
• Take this product indoors or do not use when
temperatures fall below 0°F/-18°C.
disPosAl
• Disassemble and dispose of equipment in such a manner
that no hazardous conditions such as, but not limited to,
small parts and sharp edges exist at the time equipment
is discarded.
(Recommended)
(Recommandé)
(Recomendado)
C. Front Castle Wall
Façade du château
Pared frontal del
castillo
B
B. Platform / Plateforme / Plataforma
I
I. Arch / Arche / Arco
E
E. Rail Wall / Balustrade / Baranda
P
P. Telescope
Tornillo del volante
Telescopio
