ENGLISH
endless adventures® rock climber & slide
Ages: 2 - 6 years
Please save sales receipt for proof of purchase.
adult assemblY reQuired.
WarninG:
• Keep these instructions for future reference.
• Prior to assembly, this package contains small parts: hardware which
is a choking hazard and may contain sharp edges and sharp points.
Keep away from children until assembled.
• To prevent serious injury, children must not use the equipment until
properly installed.
• Falls onto hard surfaces can result in head or other serious injuries.
Never place on concrete, asphalt, wood, packed earth, grass or other
hard surfaces. Carpet over hard floors may not prevent injury. Always
use protective surfacing on the ground under and surrounding
the playground equipment according to the enclosed "Consumer
Information Sheet for Playground Surfacing Materials." Maximum
fall height protection up to 2 feet (.6 m) required.
• Adult supervision required. Do not leave children unattended.
• This product is intended for use by children ages
2 - 6 years.
• Maximum weight per child: 60 lbs. (27 kg). Limit 3 children.
• Shoes must be worn at all times.
• This product is intended for indoor or outdoor domestic family use
only.
• Observing the following statements and warnings reduces the
likelihood of serious or fatal injury.
• Place this product on level ground and at least 6' (2 m) away from any
object. Objects to be avoided include, but are not limited to, fences,
buildings, overhead branches, laundry lines or electrical wires.
• It is recommended that the orientation of the assembled product
be such that direct sunlight is minimized on surfaces intended for
standing or sitting.
• Instruct children on proper use of this product, only after properly
placed, and not in a manner other than intended.
• Do not allow children to climb on product when product is wet.
• Instruct children not to attach items to the product that are not
specifically designed for use with the product such as, but not limited
to, jump ropes, clotheslines, pet leashes, cables and chains, as they
may cause a strangulation hazard.
• Instruct children to remove their bike or other sports helmet before
playing on this product.
• Dress children appropriately: do not allow children to wear loose-
fitting clothing including ponchos, scarves and garments with
drawstrings. Well-fitting shoes must be worn at all times.
• Protect your eyes. Always wear safety glasses when using a hammer.
Adult assembly required / Le montage devra être effectué par un adulte /
Debe ser armado por un adulto
Tools required:
Outils Requis:
Herramientas
Requeridas:
Parts List / Liste des Pieces / Lista de Partes
a
A. Side Castle Wall / Mur latéral du château /
Pared lateral del castillo Castle Wall
G
G. Bush Wall / Mur-buisson / Pared de arbustos
d
D. Ladder / Échelle / Escalera
J. Plank Front L. Rock Front
Pièce avant de planche
Pièce avant de pierre
Frente del soporte
Frente de la roca
K. Plank Rear
M. Rock Rear
Pièce arrière de planche Pièce arrière de pierre
Parte trasera del Parte trasera de la roca
soporte
1
7 / " (1.11 cm) socket
16
Clé à douille de 1,11 cm
7
Llave tubular de 1,11 cm ( / ")
16
7 / " (1.11 cm) socket
16
Clé à douille de 1,11 cm
7
Llave tubular de 1,11 cm ( / ")
16
c
H
H. Slide / Toboggan / Tobogán
F
F. Log Threshold
Marchepied de rondins
Umbral de leño
n
J x4
k x4
l x5
m x5
o
N. Steering Wheel
Gouvernail
Volante
O. Steering Fastener
Pièce d'attache du
gouvernail
Steering Fastener
(Recommended)
(Recommandé)
(Recomendado)
#2 phillips extension
Extension pour tournevis cruciforme n° 2
Extensión Phillips nº 2
C. Front Castle Wall
Façade du château
Pared frontal del
castillo
b
B. Platform / Plateforme / Plataforma
i
I. Arch / Arche / Arco
e
E. Rail Wall / Balustrade / Baranda
P
P. Telescope
Tornillo del volante
Telescopio
Q x3
1 / " Screw
1
2
Vis de 3.81 cm (1 / po)
1
2
Tornillo de 3.81 cm (1 / ")
1
2
