To change the button cell (11), unlock the locking mechan-
ism of the battery cover (2) and fold up the battery
cover (3).
Unscrew the screw of the battery compartment cover (9)
and remove the battery compartment cover (10).
Remove the empty button cell and insert a new button cell.
Reattach the battery compartment cover with the screw.
Battery charge indicator
The green LEDs on the battery charge indicator indicate the
state of charge of the battery. For safety reasons, it is only
possible to check the state of charge when the power tool is
not in operation.
Press the button for the battery charge indicator or
show the state of charge. This is also possible when the bat-
tery is removed.
If no LED lights up after pressing the button for the battery
charge indicator, then the battery is defective and must be
replaced.
Battery model GBA 18V...
LEDs
3× continuous green light
2× continuous green light
1× continuous green light
1× flashing green light
Battery model ProCORE18V...
LEDs
5× continuous green light
4× continuous green light
3× continuous green light
2× continuous green light
1× continuous green light
1× flashing green light
Control Via App
The cordless worklight is fitted with a Bluetooth® module
which enables wireless data transfer to certain mobile
devices with a Bluetooth® interface (e.g. smartphone, tab-
let).
In order to control the cordless worklight via Bluetooth®, you
will need the "Bosch Toolbox" app. Download the app from
the corresponding app store (Apple App Store, Google Play
Store).
Then select the "My Tools" subitem in the app. The display of
your mobile device will show you all subsequent steps re-
quired to connect the cordless worklight to the device.
Bosch Power Tools
The following functions will be available when a connection
has been established with the mobile device:
– Remote control
– Time control
– Grouping several cordless worklights
– Personalisation
– Status check, output of warning messages
– General information and settings
– Management

Practical Advice

Shortly before the cordless worklight switches off because
of an empty battery, it will flash three times and shine with
to
reduced brightness.
The cordless worklight will flash five times just before it is
about to switch off due to the time control.
You can adjust the time control via the app(see "Control Via
App", page 13).
Errors – causes and corrective measures
Cause
A Bluetooth® connection cannot be established with the
cordless worklight.
Capacity
The cordless worklight is not
60−100 %
emitting a Bluetooth® signal.
30−60 %
5−30 %
The cordless worklight cannot be operated via
0−5 %
Bluetooth® even though the battery is inserted and
charged.
The Bluetooth® module is not
activated.
Capacity
The cordless worklight cannot be switched on after
80−100 %
wireless charging.
60−80 %
The inductively chargeable
battery has to be re-initial-
40−60 %
ised.
20−40 %
The PIN for the Bluetooth connection is not working.
5−20 %
The PIN must be reset to
0−5 %
factory settings.

Maintenance and Service

Maintenance and Cleaning

Remove the battery from the power tool before carry-
u
ing out work on the power tool (e.g. maintenance,
changing tool, etc.). The battery should also be re-
moved for transport and storage. There is risk of injury
from unintentionally pressing the on/off switch.
The cordless worklight is maintenance-free and does not
contain any parts that need to be replaced or maintained.
English | 13
Corrective measures
Remove the button cell (11)
and battery (14) for 10
seconds.
Press the on/off switch (1)
repeatedly until the cordless
worklight can be operated
via Bluetooth®.
Remove the battery (14) for
10 seconds.
Remove the button cell (11)
and battery (14) for 10
seconds.
