ASSEMBLY - MONTAGE - MONTAJE - MONTAGGIO - MONTAŻ
ASSEMBLY - MONTAGE - MONTAJE
MONTAGGIO - MONTAŻ
Distance from the clamp
to the ground level
clamp no.
1A. 2A. 3A.
1B. 2B. 3B. 4B.
1C. 2C. 3C. 4C.
GROUND LEVEL
dimension 'x'
4A.
2060 mm
1170 mm
280 mm
23
Instructions for use - M370.113 - 'TUNNEL'
