Loewe SoundVision
Supplement to the manual
New functions starting from SW V3.x
Connection
You can also connect a Loewe subwoofer with an audio link inter-
face to the LINK (2.5 mm jack) on the SoundVision. The subwoofer
is attached by using a subwoofer adapter cable that is available as
an accessory. You can use the speakers that are integrated into the
SoundVision or external speakers that are attached to the subwoofer.
Setting up Bluetooth devices
You can connect music sources, speakers or headphones wirelessly
over Bluetooth. The devices must support the Bluetooth protocol A2DP.
Call up the Options menu.
Call up the Settings menu.
Select the Bluetooth option.
Select the option Bluetooth - on.
Select the option Continue.
The system will now search for Bluetooth devices in the
vicinity of SoundVision. Any devices that are found will
be shown on the left hand side of the list.
Select Pair for the desired device.
A keyboard will then appear; use it to enter the Blue-
tooth PIN of the device that you wish to connect to (this
is usually 0000) and then confirm it with Set.
You may need to confirm this on the device that is being
connected as well. Please OK this when asked.
You can delete connected devices from the list by using
the option Remove.
End the search with Back.
➠
The Bluetooth connection can only be initiated by SoundVision.
➠
You may need to activate the "visibility" function in the settings of
the device that is being connected to.
Sound
Speaker selection
You can also play back the sound through external speakers or head-
phones that are connected via Bluetooth. The Bluetooth device must
be connected as above described before this can happen.
Set value or option.
System speakers Speakers that are integrated into SoundVision
[BT name] External Bluetooth speaker or headphones
➠
After the device has been selected, it takes about a second before
the external speaker begins to emit audio signals.
- 6 - - 6 -
Display
DLNA remote control if this option is set to On, SoundVision can be
remote controlled by DLNA compatible devices
(Digital Media Controller). This means that you
can play music from a DLNA compatible audio
server (Digital Media Server) via SoundVision.
Sound System
In the Sound System menu, you can choose to play back sound using
either the internal speakers or a Loewe sound system that is externally
connected.
Call up the Options menu.
Call up the Settings menu.
Call up the Sound System option.
Con guration
Set value or option.
Standard Sound is played back either through the
integrated speakers or through whichever
device is currently selected in the menu
Speaker selection
Active speakers 2.0 The sound is played back in stereo over an
active speaker that is externally connected.
Active speakers 2.1 The sound is played back over a Loewe 2.1
sound system that is externally connected.
Confirm selection with Set.
Active speakers 2.1
You can set the parameters for the subwoofer in the Active speaker
2.1 menu
Set value or option.
Cutoff Frequency The option Cutoff Frequency allows you to
set the limit frequency for bass playback.
Depending on which speakers you have
attached, this can be between 20 Hz and
200 Hz.
Level The option Level allows you to set the basic
bass volume to the level of your choice.
Phase The Phase can be set between 0° and 180°
to provide optimal bass playback.
Confirm selection with Set.
.
