No. Description
1
ATX 12V Power Connector (ATX12V1)
2
CPU Fan Connector (CPU_FAN1)
3
Chassis Fan Connector (CHA_FAN2)
4
2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)
5
ATX Power Connector (ATXPWR1)
6
SATA2 Connector (SATA_2)
7
SATA2 Connector (SATA_1)
8
Chassis Fan Connector (CHA_FAN1)
9
Chassis Speaker Header (SPEAKER1)
10 System Panel Header (PANEL1)
11
Clear CMOS Jumper (CLRCMOS1)
12
Power LED Header (PLED1)
13
SATA2 Connector (SATA_4)
14
SATA2 Connector (SATA_6)
15
SATA2 Connector (SATA_5)
16 SATA2 Connector (SATA_3)
17
USB 2.0 Header (USB8_9)
18
USB 2.0 Header (USB6_7)
19
Infrared Module Header (IR1)
20 COM Port Header (COM1)
21
SPDIF Out Connector
22 Front Panel Audio Header (HD_AUDIO1)
2
(HDMI_SPDIF1)
