Expansion
AMD Ryzen series CPUs (Summit Ridge and Pinnacle Ridge)
• 1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode)*
Slot
• 1 x PCI Express 2.0 x16 Slot (PCIE3: x4 mode)
(X370M
Pro4 R2.0
AMD 7
• 1 x PCI Express 3.0 x16 Slot (PCIE2: x8 mode)*
/ AB350M
• 1 x PCI Express 2.0 x16 Slot (PCIE3: x4 mode)
Pro4 R2.0)
AMD Ryzen series CPUs (Raven Ridge)
• 1 x PCI Express 3.0 x16 Slot (PCIE2: x8 mode) (If you use
Athlon 2xxGE series APU, PCIE2 slot will run at x4 mode.)*
• 1 x PCI Express 2.0 x16 Slot (PCIE3: x4 mode)
* Supports NVMe SSD as boot disks
• 1 x PCI Express 2.0 x1 Slot
• Supports AMD Quad CrossFireX
Expansion
AMD Ryzen series CPUs (Summit Ridge and Pinnacle Ridge)
• 1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode)*
Slot
• 1 x PCI Express 2.0 x16 Slot (PCIE3: x2 mode)
(A320M
Pro4 R2.0)
AMD 7
• 1 x PCI Express 3.0 x16 Slot (PCIE2: x8 mode)*
• 1 x PCI Express 2.0 x16 Slot (PCIE3: x2 mode)
AMD Ryzen series CPUs (Raven Ridge)
• 1 x PCI Express 3.0 x16 Slot (PCIE2: x8 mode) (If you use
Athlon 2xxGE series APU, PCIE2 slot will run at x4 mode.)*
• 1 x PCI Express 2.0 x16 Slot (PCIE3: x2 mode)
* Supports NVMe SSD as boot disks
• 1 x PCI Express 2.0 x1 Slot
• Integrated AMD Radeon
Graphics
Series APU*
• Integrated AMD Radeon
APU*
* Actual support may vary by CPU
• DirectX 12, Pixel Shader 5.0
• Shared memory default 2GB. Max Shared memory supports
up to 16GB.
* The Max shared memory 16GB requires 32GB system memory
installed.
• Three graphics output options: D-Sub, DVI-D and HDMI
th
A-Series APUs
th
A-Series APUs
TM
Vega Series Graphics in Ryzen
TM
R-Series Graphics in A-series
X370M Pro4 R2.0
AB350M Pro4 R2.0
A320M Pro4 R2.0
TM TM
and CrossFireX
