Specifications
Physical *
Depth:
812mm / 32"
Height:
251mm / 9.9"
Width:
1015mm / 40"
Weight:
40.6 Kg / 89.5 pounds
Power:
< 300 Watts
Boxed size:
1220mm x 1090mm x 560mm / 48" x 42.9" x 22"
Boxed weight:
82.5 Kg / 181.9 pounds* All values are approximate
Environmental
Temperature
Operating:
Non-operating:
Max. gradient:
Relative
Operating:
Humidity
Non-operating:
Max. wet bulb:
Vibration
Operating:
Non-operating, power off:
Shock
Operating:
Non-operating:
Altitude
Operating:
Non-operating:
Connections
Power
IEC320 3-pin connector
I/O
25-pin D-type socket
iJack
Un-balanced, 3.5mm. 0.125" Stereo Jack
Speakers
Balanced, 3-pin XLR-M
Headphones
Un-balanced, 6.35mm/0.25" Stereo Jack
Performance
Channel Line/Alt In to Channel Out (post fader):
Frequency Response 10Hz – 40kHz ±0.2dB
THD+N
Noise
Headroom
Channel Line/Alt In to Mix Buss (single fader):
Frequency Response 10Hz – 40kHz ±0.3dB
THD+N
Noise
Headroom
Electro Magnetic Compatibility
EN55103-1:2009, EN55103-2:2009
Environment E4
Initial in-rush current
5 sec in-rush current
Braid-screened cables should be used where applicable. Star Quad cables should be used where applicable
EMC Performance Criteria
Line level inputs and outputs, Measure at mid-gain, noise <–56dBu
XL-Desk Safety & Install Information:
+5 to 30 deg. C
–20 to 50 deg. C
15 deg. C/hour
20 to 80%
5 to 90%
29 deg. C (non-condensing)
< 0.2 G (3 – 100Hz)
< 0.4 G (3 – 100Hz)
< 2 G (10ms max.)
< 10 G (10ms max.)
0 to 3000m (above sea level)
0 to 12000m
100 – 240 Vac, 50 –60 Hz
Zi > 10kΩ
Zi > 47kΩ, +12dB gain
Zo ≈ 100Ω
Zo ≈ 40Ω
< 0.05% (20Hz – 20kHz)
< –86dBu (20Hz – 20kHz)
> +24dBu (into 10kΩ)
< 0.05% (20Hz – 20kHz)
< –83dBu (20Hz – 20kHz)
> +24dBu (into 10kΩ)
3.2A
3.2A
This is SSL.
www.solidstatelogic.com
