DIRIS A20
INSTALLATION
RÉSEAU BIPHASÉ (2BL)
GB Two-phase network (2BL)
D Zweiphasennetz (2BL)
I
Rete bifase (2BL)
NL Tweefasennet (2BL)
E Red bifásica (2BL)
P Rede bifásica (2BL)
RÉSEAU MONOPHASÉ (1BL)
GB
Single-phase network (1BL)
D Einphasennetz (1BL)
I
Rete monofase (1BL)
NL Enkelfasenet (1BL)
E
Red monofásica (1BL)
P Rede monofásica (1BL)
Find Quality Products Online at:
16 DIRIS A20 - Ref.: 535746 A
GlobalTestSupply
www.
I1 I2 I3
S1 S2 S1 S2 S1 S2
S1
P1
1 Aux.: IEC /CE
2 Fus.: 0.5 A gG / BS 88 2A gG / 0.5 A class CC
I1 I2 I3
S1 S2 S1 S2 S1 S2
S1
P1
1 Aux.: IEC /CE
2 Fus.: 0.5 A gG / BS 88 2A gG / 0.5 A class CC
.com
V1 V2 V3 VN AUX
2
1
2
L1 ( R )
L2 ( S )
110... 400V AC
120... 350V DC
V1 V2 V3 VN AUX
2
1
2
L1 ( R )
N
110... 400V AC
120... 350V DC
