Senio
| Rollator
4.
Assembly/adjustments
4.1. Fitting push handles
•
Insert the push handles in the handle tubes and slide the screw
through the holes from inside to outside.
•
First, slide the curved plastic adapter onto the screw so that
it conforms to the tube. Then push the washer onto the screw
4
(Fig.10).
•
Place the star nut on the screw and tighten (Fig.11).
•
To set the correct height, read section 4.5
4.2.
Unfolding
•
Position the rollator in the travel direction.
•
Release the locking brakes (see sec. 4.5).
5
•
Tip the B+B rollator towards yourself until the load is taken off the
steered wheels and press the handles downwards at the same time
with a gentle jolt.
•
To lock the folding mechanism, now fold the seat plate tight to
your seat (Fig. 4). This locks the rollator.
4.3.
Folding
6
•
Position the rollator in the travel direction.
•
Activate the locking brakes.
•
To unlock, pull the unlocking mechanism to the left on the right-
hand side (Fig. 7).
•
Hold the rollator firmly with both hands and tilt it by pulling it
towards you.
7
34
Note that the rollator may suddenly fold up when
the lever is activated.
•
For unlocking, take one hand off the handle and use it to activate
the lever of the auto-lock system (Fig. 7). Ensure that neither body
parts nor pieces of clothing become pinched during the folding
process.
•
To fold the rollator up completely, pull the handles towards you.
4.4.
Attach basket and tray
•
The rollator is unfolded. Activate the locking brakes.
•
Position yourself against the travel direction in front of the rollator.
•
Simply hang the basket onto the hooks attached to the front frame
tubes (Fig. 8)
•
To remove the basket, simply hold the carrying handle in your hand
and move it upwards to remove
•
Place the tray onto the seat from above in such a way that the four
plastic pins of the tray fit into the holes of the seat (Fig. 9).
4.5.
Adjusting the push handles
•
The B+B rollator is unfolded. Activate the locking brakes.
•
Position yourself behind the B+B rollator and let your arms hang
down in a relaxed manner.
•
Now adjust the push handles so that they are at the level of your
wrists.
•
Push the screw from inside to outside through the hole closest to
this height. Place the curved plastic adapter and then the washer
on the screw (Fig.10).
•
Place the star nut on the thread and tighten (Fig. 11).
•
Repeat this procedure on the other side.
•
Check to make sure that both the push handles are at the same
height.
Bischoff & Bischoff GmbH |01.11.2019 - revision: 1
Senio
Rollator |
8
8
9
9
10
11
35
