Product Safety Information

Intended Use:
These Riveting Hammers are designed for light weight riveting applications.
For additional information refer to Product Safety Information Manual Form 04581450.
Manuals can be downloaded from ingersollrandproducts.com.

Product Specifications

Model Handle
AVC10C1 button throttle
AVC10C1-EU button throttle
AVC10A1
AVC10A1-EU
AVC12A1
AVC12A1-EU
AVC13A1
AVC13A1-EU
AVC26A1
AVC26A1-EU
AVC26B1 pistol grip
AVC26B1-EU pistol grip
† K = 3dB measurement uncertainty
pA
‡ K = 3dB measurement uncertainty
wA
Sound and vibration values were measured in compliance with internationally recognized test standards. The exposure to the user in
a specific tool application may vary from these results. Therefore, on site measurements should be used to determine the hazard level
in that specific application.
Installation and Lubrication
Size air supply line to ensure tool's maximum operating pressure (PMAX) at tool inlet. Drain condensate from valve(s) at low point(s) of piping,
air filter and compressor tank daily. Install a properly sized Safety Air Fuse upstream of hose and use an anti-whip device across any hose
coupling without internal shut-off, to prevent hose whipping if a hose fails or coupling disconnects. See drawing 16576175 and table on
page 2. Maintenance frequency is shown in a circular arrow and defined as h=hours, d=days, and m=months of actual use. Items identified as:
1. Air filter
2. Regulator
3. Lubricator
4. Emergency shut-off valve
5. Hose diameter
Note: Before storing the tool or leaving idle exceeding 24 hours:
- Pour 3 cm of Ingersoll Rand # 10 oil into air inlet and run tool for 5 seconds.
3
Adjustments
Always turn off the air supply, bleed the air pressure and disconnect the air supply hose when not in use, before installing, removing or
adjusting any accessory on this tool, or before performing any maintenance on this tool or any accessory.
Keep the Handle tight on the Barrel.
After the first 24 hours of operation, remove the Exhaust Deflector and Locking Key. Clamp the Barrel flats in a leather-covered or copper-
covered vise and using a wrench at least 12" (305 mm) long, draw the handle as tightly as possible. For aluminium handles, tighten to 160 ft-lb
(216 Nm) torque. For all other Handles, tighten to 180 ft-lb (244 Nm) torque.
Do not attempt to pry apart the two sections of the Valve Box. Grasp the front section in the hand and insert a rod that will pass through the
Valve and contact the rear section. Lightly strike the rod until the two sections are separated.
Keep the front and rear sections of a Valve Box as a unit. They are factory matched and must not be mismatched.
03528742_ed15
Power Blows per
Regulator
---
---
offset built-in
offset built-in
offset built-in
offset built-in
offset built-in
offset built-in
offset built-in
offset built-in
built-in
built-in
6. Thread size
7. Coupling
8. Safety Air Fuse
9. Oil
10. Oil - before starting, into air inlet
Piston Stroke
min.
Inch (mm) † Pressure (L
3,200 1-7/8 (47)
3,200 1-7/8 (47)
3,200 1-7/8 (47)
3,200 1-7/8 (47)
2,100 3 (76)
2,100 3 (76)
1,725 4 (101)
1,725 4 (101)
1,120 6 (152)
1,120 6 (152)
1,120 6 (152)
1,120 6 (152)
WARNING
WARNING
NOTICE
Sound Level dB (A)
(ISO15744)
‡ Power
)
(L )
p
w
92.0 103.0
92.0 103.0
92.0 103.0
92.0 103.0
91.1 102.1
91.1 102.1
94.2 105.2
94.2 105.2
92.6 103.6
92.6 103.6
92.6 103.6
92.6 103.6
* K = Vibration measurement uncertainty
EN
Vibration (m/s )
2
(ISO28927)
Level *K
13.3 1.9
13.3 1.9
13.3 1.9
13.3 1.9
8.0 1.8
8.0 1.8
8.0 1.8
8.0 1.8
8.0 1.8
8.0 1.8
8.0 1.8
8.0 1.8
EN-1
