CLEANING AND MAINTENANCE

We recommend a frequent cleaning of the speaker system. Please use a soft lint-free and moistened cloth.
Never use alcohol or solvents!
There are no serviceable parts inside the speaker system. Maintenance and service operations are only to
be carried out by authorized dealers.
If the speaker system distorts, one of the loudspeakers may be defective. Test the speaker system once
more with another amplifier. If the sound remains distorted, the speaker-system should not be operated any
more in order to prevent further damage. Please contact your dealer.
If clacking sounds are heard from the speaker system, screws may have loosened due to the continuous
vibrations. The speaker system should be checked by a specialist. Especially for public use, the speaker
system should be checked before every operation so that the speaker system and the speakers in the
systems are always well fixed.
Should you need any spare parts, please use genuine parts.
Should you have further questions, please contact your dealer.

TECHNICAL SPECIFICATIONS

Rated power:
Program power:
Components:
Connections:
Sensitivity (1 W/m):
Max. SPL (1 m):
Impedance:
Frequency range:
Dimensions (H x W x D): 580 x 460 x 590 mm
Weight:
Please note: Every information is subject to change without prior notice. 10.12.2012 ©
11039621 OMNITRONIC
PAS-151 PRO
500 W RMS
1000 W
15" woofer
2 Speaker sockets
97 dB (1 W, 1 m)
127 dB (1 m)
8
45 - 200 Hz
32 kg
11039622 OMNITRONIC
PAS-152 PRO
1000 W RMS
2000 W
2 x 15" woofer
2 Speaker sockets
101 dB (1 W, 1 m)
133 dB (1 m)
4
40 - 200 Hz
610 x 957 x 482 mm
55 kg
18/22
11039623 OMNITRONIC
PAS-181 PRO
600 W RMS
1200 W
18" woofer
2 Speaker sockets
98 dB (1 W, 1 m)
129 dB (1 m)
8
40 - 180 Hz
680 x 560 x 685 mm
43 kg
00073684.DOC, Version 1.0
