- Seite 1 5° Vertical Modules 10° Vertical Modules 20° Vertical Modules 40° Vertical Modules 60° Vertical Modules RoomMatch RoomMatch ™ ™ Full-Range Array Module Loudspeaker Installation and Safety Guidelines RoomMatch Array Module Loudspeakers Instrucciones de instalación y de seguridad Installation and Safety Guidelines Installation et instructions de sécurité...
-
Seite 2: Important Safety Information
2) Obtain all mounting system components from reputable manufacturers. Select a mounting system appropriate for your loudspeaker system and its intended application. We recommend Bose mounting accessories when available. A licensed professional engineer must review the design and fabrication of any custom mounting hardware. -
Seite 3: Información De Seguridad Importante
2) Consiga todos los componentes de montaje de fabricantes de confianza. Seleccione un sistema de montaje adecuado para el sistema de altavoces y la aplicación a la que vayan destinados. Recomendamos utilizar accesorios de montaje Bose siempre que estén disponibles. Un ingeniero profesional con licencia deberá revisar el diseño y la fabricación de cualquier accesorio de montaje personalizado. - Seite 4 Faire contrôler par un professionnel qualifié la conception et la fabrication des accessoires de montage sur mesure. 3) Le module d’enceintes Array Bose RoomMatch™ est doté d’un système de fixation par plaque latérale intégré, destiné à en faciliter le montage par un installateur professionnel. La connexion entre deux modules doit être réalisée uniquement à l’aide des plaques latérales intégrées et des attaches M10 fournies.
-
Seite 5: Wichtige Sicherheitshinweise
2) Beschaffen Sie sich alle Komponenten der Halterung von renommierten Herstellern. Wählen Sie eine Halterung, die für Ihr Lautsprechersystem und die beabsichtigte Anwendung geeignet ist. Wir empfehlen Befestigungszubehör von Bose, wo verfügbar. Ein zugelassener fachkundiger Techniker muss die Auslegung und die Herstellung der benutzerspezifischen Befestigungselemente überprüfen. -
Seite 6: Installation
Installation pro.Bose.com pro.Bose.com ntroductIon Summary Description Each RoomMatch™ module is a 2-way, full-range loudspeaker designed to form Progressive Directivity Arrays for fixed-installation sound reinforcement of the highest-quality live music and speech. Overcoming the limitations of both line array and point-source con- ventional designs, RoomMatch™... -
Seite 7: Product Specifications
PecIfIcatIonS ange rray oduleS Refer to pro.Bose.com for subwoofer module and additional specifications and installation information! Frequency Response (+ / - 3 dB) 60 Hz – 16 kHz Usable Frequency Range (-10 dB) 55 Hz – 16 kHz Recommended Crossover Frequency... - Seite 8 Installation pro.Bose.com All 10˚ Vertical Modules All 20˚ Vertical Modules Page 8 Installation and Safety Guidelines English...
- Seite 9 Installation pro.Bose.com All 40˚ Vertical Modules All 60˚ Vertical Modules English Installation and Safety Guidelines Page 9...
-
Seite 10: Connector Wiring
Recommended Signal Processing Digital signal processing (DSP) equipment is required for infrasonic protection, crossover, equalization, and protection limiting functions. The recommended active crossover for the RoomMatch™ full-range modules uses the following filters in the Bose PowerMatch™ PM8500 professional amplifier or Bose ControlSpace ESP (sold separately): ®... - Seite 11 Installation pro.Bose.com Array Rigging Each RoomMatch™ array module is shipped with integrated side-plate array rigging hardware. The rigging system is designed to allow fast construction of typical fixed-installation arrays of up to 8 modules, while maintaining a 10:1 Safety Factor. Additionally, the RoomMatch™...
- Seite 12 Use RoomMatch™ Array Suspension Angle Calculator software to determine the hole positions on the array frames for required aiming angles and confirm array does not exceed load limits of frame. (You may also contact your local Bose Technical Support or Field Engineer for this information.)
- Seite 13 Installation pro.Bose.com Service Test Panel Access for Transducer Testing The RoomMatch™ module is equipped with a service test panel providing access to individual transducers for troubleshooting and ser- vice/repair operations. To access the transducer test points, loosen the 2 screws on the panel and slide the panel over the screw heads.
- Seite 14 Installation pro.Bose.com Painting the Enclosure RoomMatch™ modules can be painted using a solvent-based spray paint such as KRYLON. For best results, ensure the surface is dry and free of oils and debris. Always test a small inconspicuous area before spraying the entire product. Remove grills and paint sepa- rately.
-
Seite 15: Additional Resources
Additional Resources pro.Bose.com Visit us on the web at pro.Bose.com. Hong Kong Bose Limited Americas Suites 2101-2105, Tower One, Times Square (USA, Canada, Mexico, Central America, South America) 1 Matheson Street, Causeway Bay, Hong Kong Bose Corporation 852 2123 9000... - Seite 16 © 2012 Bose Corporation. All rights reserved. The Mountain, Framingham, MA 01701-9168 USA www.pro.Bose.com All trademarks are the property of their respective owners. AM356866 Rev. 00...
