2. EXPLODED VIEW

12
19
6
2
13
18
*included with the PH-ES614P Models only
6
7
20
1
8
10
16
Model: PH-ES614P
3
11
15
5
4
9
14
6
1. Chassis
2. Window Left Side Panel (PH-ES614P)
3. Right Side Panel
4. Front Panel
5. ODD Cover
6. Bottom Dust Filters
7. Top Panel
8. Phanteks Logo Plate
9. Front Mesh cover
10. Hard Drive Cage
11. SSD Bracket
12. PH-F140
13. PH-F200
14. Front dust filters
15. I/O Ports
16. Bottom feet
17. Closed Left Side Panel (PH-ES614PC)
18. PSU Cover (PH-ES614P)
19. Reservoir Bracket (PH-ES614P)
20. PWM Hub
17
Model: PH-ES614PC
