2. EXPLODED VIEW

12
10
11
6
4
2
8
9
1
6
3 5
7
13
1. Chassis
2. Top Panel
3. SSD Bracket
4. Fans
5. Right Side Panel
6. Front Panel
7. HDD Tray
8. Hard Drive Cage
9. Front Mesh cover
10. Left Side Panel
11. Mid-plate
12. Rear Dust Filter
13. Pump bracket
