i-box Trax Benutzeranleitung

79200R
Introduction
The Trax Bluetooth speaker allows you to listen to the music stored on your iPod™, iPhone™, or other
Bluetooth enabled device without the need to connect via wires or a dock. It can also be used as a
loudspeaker for your mobile phone calls. The NFC function allows you to make a One Touch connection
to NFC enabled devices.
Controls and connections
Fig. 1
1 2
1. Power on/off
2. Bluetooth connection*
3. Press to return to previous track(s)*
4. Answer phone call/Play/Pause*
5. Press to forward to next track(s)*
*Touch sensitive controls, activated by a light touch
Specifications
• Weight: 317g
• Dimensions: 160 x 60 x 55mm
• Advanced audio distribution profile (A2DP)
for wireless music streaming
• Hands-free audio (HFA) and Headset profiles
(HSP) for hands -free calling
• 10m (30 feet) wireless range
Trax
PorTable blueTooTh® SPeaker WITh NFC
USER GUIDE
3 4 5 6
Fig. 2
7 8
6. Volume -*
7. Volume +*
8. NFC touch point
9. AUX - IN
10. Charging indicator
11. Micro USB charging port
• Charging time: 2-2.5 hours
• Play time: 4-5 hours
• Battery voltage: 3.8 volts
• Input: 5V/500mA
• Max output power: 2 x 3 Watts + passive
sub woofer
ENG
10
9 11
