iBlast Dongle

EN
3.5 mm phone jack phone jack

Charging the iBlast dongle

Connect the iBlast module with a suitable Apple® or Android™ device
Connect the iBlast module with the 3.5 mm jack of your Apple® or Android™ device.
WARNING: the media volume must be set to maximum before the fl ight - crash hazard!
The iBlast user interface

User-Interface

ON/OFF ON/OFF
Throttle-Lever tle-Lever
16
red LED red LED
blue LED blue LED E E E E E E E E E E
• Plug the USB charging cable to a suitable USB port of your PC or a sui-
table charger or AC adapter.
• Insert the round plug in the iBlast dongle. The red LED of the module lits.
• If the battery is fully charged, the red LED turns off.
• The charging time is approx. 60 minutes, the operating time of the iBlast
module is approx. 1.5 - 2 hours.
back back
Infrared-Transmitter Infrared- ed Tran
WARN WARNING: the IR transmitter must always face towards
the models direction - risk of accident! the models d
red LED on: red LED on: iBlast dongle charging
red LED off: red LED off: iBlast dongle fully charged
blue LED on blue LED on: iBlast dongle active
blue LED blinks: dongle battery empty, stop operation immedi- blue LED bli
ately and charge battery
Rotate Interface Rotate Interface
180° 180°
Channe Channel n n l
Direction trim
iBlast module
TURBO: select s TURBO: select speed
Motion co Motion control on/off
Direction Direction stick
Help Help
EUROCOPTER iBlast
