Specifications; Install The Hardware - Axis T96B05 Installationsanleitung

AXIS T96B05 Outdoor Housing

Specifications

Operating Conditions
Temperature
-30°C to 55°C
(-22°F to 131°F)

Install the Hardware

Important
AXIS T96B05 must be mounted on a flat surface.
1. Use the supplied drill template and drill four holes for the
bottom cover screws and one hole for the network cable.
Note
When using the drill template, make sure it conforms to the
desired angle of the camera installation.
2. Remove the top cover from the bottom cover, using the top
cover tool. See image 1.
3. Remove the top cover from the P39 series camera, using the
top cover tool.
1
8
Humidity
10% to 100% RH
(condensing)
