Linksys X1000 - Cisco Linksys X-Series Benutzerhandbuch

Linksys X-Series
Specifications

Linksys X1000

Model Name Linksys X1000
Ports DSL, Cable, Ethernet (1-3), Power
Switch Port Speed 10/100 Mbps (Fast Ethernet)
Buttons On/Of, Reset, Wi-Fi Protected Setup™
LEDs Power, Ethernet (1-3), Wi-Fi Protected Setup,
Wireless, Internet
Radio Frequency 2.4 GHz
Antennas 2 Internal
Security Features WEP, WPA, WPA2
Security Key Bits Up to 128-bit encryption
UPnP Supported
Certiication FCC, UL/cUL, CE, K.21, Telepermit,
Wi-Fi (IEEE 802.11b/g/n), WPA2™, WMM®,
Wi-Fi Protected Setup, Windows 7
ADSL Standards T1.413i2, G.992.1 (G.DMT), G.992.2 (G.Lite),
G.992.3 (ADSL2), G.992.5 (ADSL2+) for Annex A,
B, M, L, U-R2 for Annex B
USB Storage Maximum supported capacity: 1 x 2 TB
Environmental
Dimensions 180 x 34 x 167 mm (7,09 x 1,34 x 6,58")
Weight 287 g (10,1 oz)
Power 12VDC, 1A
Operating Temperature 0 to 40°C (32 to 104°F)
Storage Temperature -20 to 70°C (-4 to 158°F)
Operating Humidity 10 to 85% Noncondensing
Storage Humidity 5 to 90% Noncondensing
NOTES
For regulatory, warranty, and safety information, see the CD that
came with your modem router or go to Linksys.com/support.
Specifications are subject to change without notice.
Maximum performance derived from IEEE Standard 802.11
specifications. Actual performance can vary, including lower
wireless network capacity, data throughput rate, range and
coverage. Performance depends on many factors, conditions and
variables, including distance from the access point, volume of
network traffic, building materials and construction, operating
system used, mix of wireless products used, interference and other
adverse conditions.
Specifications
