Ports and Operating Elements

Ports and Operating Elements
This chapter presents the individual hardware components of your notebook. You can
obtain an overview of the displays and connections of the notebook. Please familiarise
yourself with these items before you start to work with your notebook.
Touchpad Webcam Multimediaboard
Separatenumerickeypad Status indicators Subwoofer Memory servicecompartment Rechargeablebattery ExpressCard slot Networkport Line-outport SPDIFport Headphone port Microphoneport Line-inport HDMIport Multimediaremotecontrol Monitor port(VGA) FireWireport DCinputconnector (DCIN) eSATA/USB combinationport Harddiskservicecompartment Loudspeakers Multi-connectorport ON/OFFswitch Antennacableport USB ports Touchpad buttons Antennacableport Infrared interface forremotecontrol Keyboard Multi-formatcard reader
2
1
21
4
20
19
17
18
16
15 14
1 = Microphones
2 = Webcam
3 = Multimedia board
4 = Loudspeakers
5 = Keyboard with separate numeric keypad
and application buttons
6 = Touchpad
7 = Status indicators
8 = Touchpad buttons
9 = Infrared interface for remote control
10 = Multi-format card reader
11 = Line-in port
12 = Microphone port
13 = Headphones/Line-out port
14 = SPDIF/Line-out port
8 - English
1
3
4
6
9 8
10
11
12
13
22
23
5
24
30
7
15 = ExpressCard slot with multimedia
remote control
16 = LAN port
17 = eSATA/USB combination port
18 = Ventilation slots
19 = DC input connector (DC IN)
20 = Kensington Lock
21 = ON/OFF switch
22 = CD/DVD drive
23 = USB ports
24 = Antenna cable port (optional)
25 = Multi-connector port (optional)
26 = Monitor port (VGA)
27 = HDMI port
28 = FireWire port
26
25
31 32
33
35
10601078868, edition 1
29
28
27
34
