1a. Mount on Wood Stud Wall
• Make sure that mounting screws are anchored into the center of the studs.
Use of a stud finder is highly recommended.
• Installers are responsible to provide hardware for other types of mounting situations.
• Installers must verify that the supporting surface will safely support the combined
load of the equipment and all attached hardware and components.
17-03-421-9336CD.indb 4
1
X
D6 Washer
WARNING
4
2
Find and mark the exact
location of mounting holes
3
Drill pilot holes
Anchor Bolt
Screw the wall
plate onto the
4/3/2017 3:52:10 PM
wall
