Installing the wall-mount bracket (For Model 37 inch Separate Type)
Use the following procedures to install the Model 37 inch LCD color TV (LC-37AD1, LC-37AD2,
LC-37BD5, LC-37HV4, LC-37HV6, LC-37AA1, LC-37GD1, LC-37GD2, LC-37G4, LC-37U5-B/-R,
LC-37L5-B/-T, LC-37W5C/K).
• Be sure to use two people to perform the wall-mount bracket installation work for
the Model 37 inch LCD color TV.
Caution
• The installation work must be conducted while the Model 37 inch LCD color TV is
standing upright, so be careful that it does not fall over.
1
Remove the back terminal covers from the LCD color TV.
Remove the terminal covers while the LCD color TV is standing upright.
2
Wire in the cables.
3
Install the top terminal cover.
E-9
