2. Interface Description

Port
The WAN/POE port is used to connect to network devices, such
WAN
as a POE switch OR POE adapter.
The LAN port is used to connect to network devices, such as a
LAN
switch or PC
With the AP powered on, press the Reset button for 10 seconds
until the USB LED blink with green light and System LED on
Reset
without blink. The AP will restart itself and reset the device to
factory default settings.
USB To connect with USB storage device
12V/1.5A DC input Power Adapter .
Power
(WAP-6117 Power Adapter unit is to be ordered separately)
Description
-4-
