PS484S
Before attempting to connect or operate this product, please read instructions completely.
PRODUCT INSTRUCTIONS
Installation and operation instructions for the following models:
Pendant Mounts
Descriptions and additional units:
• PS484S
Pendant shroud
• PWM484S
Pendant shourd with wall mount bracket
• PPM484S
Pendant shroud with wall mount bracket, and pole adapter
• PCM484S
Pendant shroud with wall mount and corner adapter
•PHM484S
Pendant shroud with ceiling adapter
Manufactured for:
by
81-IN3097
09/25/09

Werbung

loading

Inhaltszusammenfassung für Moog Videolarm PS484S Series

  • Seite 1 Manufactured for: PS484S Before attempting to connect or operate this product, please read instructions completely. PRODUCT INSTRUCTIONS Installation and operation instructions for the following models: Pendant Mounts Descriptions and additional units: • PS484S Pendant shroud • PWM484S Pendant shourd with wall mount bracket •...
  • Seite 2: Important Safeguards

    IMPORTANT SAFEGUARDS SAFETY PRECAUTIONS Read Instructions - All the safety and operating instructions should be read before the unit is operated. CAUTION Retain Instructions - The safety and operating RISK OF ELECTRIC SHOCK instructions should be retained for future DO NOT OPEN reference.
  • Seite 3 Wrap Teflon tape around the pipe threads Securely mount bracket to wall. Pull wiring to ensure a tight seal. through bracket and position grommet as shown. • Con seguridad soporte del montaje a emparedar. Tire del cableado • La cinta del Teflon del abrigo alrededor de la pipa rosca a través del soporte y del ojal de la posición según lo demostrado.
  • Seite 4 WV-NW484 (with base) WV-NW484 (without base) WV-CW484 (with base) 1" 1 1/2" 1 1/2" 1/2" WV-CW474 WV-NW474 WV-CW484 (mounting plate) WV-NW502S Add spacers as specified for the camera you are using. • Agregue los espaciadores según lo especificado para la cámara fotográfica que usted está utilizando. •...
  • Seite 5 WV-NW484 WV-NW484 Secure hardware to pendant shroud. Align trim ring and dome with base and secure with security tool. • Segura de hardware para colgante sudario. • Alinee anillo y con la base y la cúpula seguro con herra- mienta de la seguridad. •...
  • Seite 6 WV-CW484 (&) WV-NW502S WV-CW484 (&) WV-NW502S Notch Be sure to align notch in mounting plate with Align trim ring and dome with key slots in molded boss in camera base. mounting plate and secure. • Asegúrese de alinear la muesca en la placa de montaje con •...
  • Seite 7 WV-CW474 WV-CW474 Add spacers as shown in frame 5 and Attach camera base to pendant shroud, add complete wiring connections. trim ring and dome, secure properly. • Añadir espaciadores como se indica en el cuadro 5 y • Conecte la cámara a la base de velo colgante, anillo y añadir cúpula, seguro correctamente.
  • Seite 8 PS484S 1 1/2-11.5 NPT 1.858 5.551 7.440 7.665 SECTION A-A...
