Symbols,
The following figure displays all the symbols found on the BayStack 10 Power Supply
Unit (PSU) and its component parts, and the following legend provides the explanation.
You may not use all the components, so you may not see all the symbols shown here.
1
2
3
4
Legend:
1 = On/Off in ON mode
2 = UPS in standby mode
3 = Alternating current voltage
4 = Protective earth
5 = Direct current voltage
6 = Not for telecommunication (telephone) network
7 = Risk of electric shock
8 = Phase
14
5
6
7
8
