3.4 Assignment of the DMX channels in the overview:

NOTE: Basic knowledge of the DMX512 control standard is required so that the device can be correctly
operated and programmed with a DMX controller.

2-Channel Mode:

Channel Value
CH1 0-255
0-9
10-19
20-29
30-39
40-49
50-59
60-69
70-79
80-89
90-99
CH2 100-109
110-119
120-129
130-139
140-149
150-159
160-169
170-179
180-189
190-199
200-255
3 Channel Mode:
Channel Value
CH1 0-255
CH2 0-255
CH3 0-255
5 Channel Mode:
Channel Value
CH1 0-255
CH2 0-255
0-9
CH3
10-19
Function
Dimmer from 0 – 100%
No Function
Red from 0 – 100%
Green from 0 – 100%
Blue from 0 – 100%
White from 0 – 100%
Amber from 0 – 100%
UV from 0 – 100%
Yellow
Magenta
Cyan
Dark orange
Green yellow
Salmon
Turquoise
Light Green
Orange
Straw
Lavender
Light blue
Dark blue
Pink
Function
Red from 0 – 100%
Green from 0 – 100%
Blue from 0 – 100%
Function
Dimmer from 0 – 100%
LED Stroboscope (0-100%)
No Function
Red from 0 – 100%
