- Connect the supply cable to the power source box based on the diagram keeping a sufficient reserve of its
length.
- Connect the central light to the light cable. If you use the existing installation, it may be necessary to extend
the supply cable sufficiently.
- If the local situation and valid standards require so, perform the connections with the protective wires and
with all the items specified by the standard. For the connection, use the mechanically protected copper wire of
2
2,5 mm section with a yellow-green isolation.
- If the ventilator control is designed, connect it to the power source.
- All the connection cables must have a round section to keep the sufficient covering. Unused bushings must be
fitted with a substitute plug. All cable bushings of the power source must be duly tightened due to a mechanical
security of the cables and keeping the assigned covering.
- Put COMPACT 1 to the ceiling and fasten it by the screw to the holder. In order to level it on the ceiling use the
adjustment screws on swivel hinges.

Putting the System to Operation

- After checking the connection and the fixing of the covers, you can switch on the power supply check all
functions to their full extent based on the operating instructions.
- finally fix the remote controller.
The assembly organization will confirm the warranty certificate and will submit to the user the assembly
!
!
manual together with the operating instructions. It will inform the user with the function and operation of
the system.

Maintenance and Servicing

The device does not require any special maintenance. When cleaning, do not use abrasive detergents (for
instance grinding pastes, etc.) or aggressive chemicals (containing the solvents, acids and lyes). In the space,
where the device is installed, it is not permitted to use the cleansing detergents, their vapors are aggressive to
the metal parts (for instance hydrogen chloride acid). Regular maintenance is carried out only by wiping the
parts and the glass with a wet cloth and the system switched off. To remove old and stubborn stains, use
RAVAK CLEANER.
Replacement of Batteries in the Remote Controller
If the LED indicator (marked with 8 in Fig. No. 1) on the controller does not flash after pressing a button or the
device does not respond to the pressing of buttons of the remote controller, it is necessary to replace the
batteries. In order to replace them, use the screwdriver and two new alcaline batteries, with which you can be
sure that the contacts of the holder and the remote controller electronics are not polluted and damaged. After
the removal of the controller, unscrew two screws on the rear side, remove the cover and replace the batteries.
Check the intactness and the correct positioning of the sealing under the cover. After the repeated covering of
the battery compartment, tighten reasonably both screws and test the function.
Water or humidity must never enter the inside of the remote controller. If humidity still gets in, replace the
batteries and leave the uncovered controller dry up thoroughly (on a moderately dry place, for instance
!
above the central heating radiator).
Replacement of a Defective Bulb in the Central Light
Switch off the whole system and wait till the defective bulb cools down. Carefully pull the plate in the
direction from the light rim, release the glass and after it swivels slightly remove it. Remove the defective
bulb by pressing the ceramic holder on one side and by pushing the bulb simultaneously in the opposite
holder. Put in a new bulb of the same type and output recommended in the manual applying the reversed
process. You may not touch the bulb with your fingers and if this still happens, clean it with a degreasing
detergent. Push the new bulb, slightly offset, against the final position into one holder while pressing
simultaneously the second holder. Then align the bulb in the axis of the holders and release the strengths
expanding the holders from one another. In the end fix in the protective glass. By using the pressure on the
plate, push in the slightly inclined glass to one side of the frame, align it flat and after releasing the pressure, the
glass will go in the frame slot by about 2 mm also on the side of the plate.
Replacement of the Defective Bulb in the Spot Light
Switch off the whole system and wait till the defective bulb cools down. Release the springy wire fuse
below the bulb which will allow you to pull the bulb down. Slightly turn the bayonet socket to release the
defective bulb. Replace it with a new bulb of the same type and output recommended in the manual in
the socket by turning it in. Put the bulb in the holder and secure it with the wire fuse.
