Installation instructions

2.2 Assembly instructions

1. Take out the fan body and the spare parts from the box. Put the front base onto rear base and join
them together. (See Fig. 1)
2. Pass the power cord through the flute, then insert the fan body into the base. (See Fig. 3)
3. Fix the fan body on the base with the plastic nut. (See Fig. 2)
Fig. 1
Fig. 2
Tower Fan / User Manual
The outlet trough
Fig. 3
7 / 12 EN
