3. Assembling the pushchair

1. Release the latch
2. Open the pushchair by lifting up the handlebar. Click the sides into place.
3. Assemble the back wheels on the axis, respecting the order of the clips and the discs.
4. Assemble the back wheels onto the frame.
5. Assemble the front wheels as indicated.

4. Using the pushchair

6. Inclination of the backrest : slide the zipper to the end of the strap and select the desired slope.
7. Press the rear brake to turn it on, pull it up to release.
8. Press the front brake down to lock the wheels or or pull up for swiveling wheels.
9. Click the upper tray in place.
10. Pull the leg rest up to the fully reclined position. Press simultaneously the push buttons on the sides of the leg
support and push it down to the sitting position.
11 A. Open the seat belts by pressing the button of the buckle.
11 B-C. Close the lumbar belts and adjust the straps to the circumference of your child.
11 D. Close the shoulder straps and adjust the belts to the length of your child.
