Installation; Preparations - Sony DSBK-180 Installationsanleitung

Installation

Preparations

Before installing the board into the VCR, first connect the two
ribbon cables to the PP-55 board. (Take care not to insert the
cable upside down.)
The ribbon cable connectors are equipped with locks. Make
sure the connectors are unlocked before inserting the ribbon
cable, and close the locks after the ribbon cables are inserted.
10
Caution
If this option is installed incorrectly, personal injury or
damage to peripheral items may occur due to fire, shock,
or other accidental circumstances. To avoid such risks,
installation should be performed by qualified service
personnel.
Unlocked
Insert the cables so that the end panels are facing upward.
Locked
