Bitronics AutoSwitch Set Benutzerhandbuch Seite 11

P73121/F1U126-KIT/EU/man.qxd
When two PCs are connected to the AutoSwitch, they can exchange files
through any standard file transfer program such as Windows
Connection, Interlink
NOTE: Port A can only file transfer to Port B and Port C to Port D only.
If a pair of computers are in file transfer mode (example: A to
B), computers C and D still have access to the shared device.
See the examples below for the different operating systems:
A. Windows ®
To do this, double-click on the "Bitronics" icon shown in the system tray:
The Bitronics Software will pop-up:
• Click on the pull-down menu on the upper right side if the Bitronics
switch is connected to LPT2 or LPT3. The default and most common
setting is LPT1.
• Click on "Multiple PCs sharing 1 Device".
• Click on "File Transfer".
4/28/00 1:06 PM
File Transfer Function
or LapLink .
™ ®
95/98 and Windows NT
7
Page 7
® Direct Cable
® :
En
