Mounting using the stand
1. If required, use the 3 supplied screws to fix the base
plate to a flat (horizontal or vertical) surface.
2. To use a shorter stand, unscrew the lock ring to release
the camera, and remove the extension section.
3. Attach the camera, adjust the angle and tighten the lock
ring.
Shelf mounting
1. Position the clamp and tighten the fixing screw securely.
2. Attach the clamp to the lock ring on the camera.
3. Adjust the angle and tighten the lock ring.
Important!
The AXIS 207/207W is designed for indoor use only, and must always be positioned where it is not exposed
to direct sunlight or strong halogen light, which can cause permanent damage to the camera's image sen-
sor. Damage as a result of exposure to strong light is not covered by the Axis warranty.

Cable Connections

1. Using the self-adhesive strip, attach the supplied cable clip to the rear panel and fasten the
power cable to it. This will prevent accidental cable disconnection.
2. Connect the camera to the network using a standard network cable. For the AXIS 207W,
this connection is temporary and allows the camera's settings to be configured via the
wired network before connecting to the wireless network. If required, the AXIS 207W can
be used solely as a wired camera, in which case the network cable should be left
connected.
3. Connect the power adapter to the camera.
4. See Setting the IP address, on page 6 for the available options.
