EN: Installation Sheet
Package
The package contains:
• 1 x DDI602
• 1 x drilling template for fixing holes
• 1 x hex wrench
• 2 x 31.75 mm / 1.25 in. wall plugs
• 2 x 31.75 mm / 1.25 in. screws
• 1 x lens mask
• 2 x additional curtain shutters
• 1 x tamper cup
• 2 x tamper caps (different lengths)
• 1 x plastic locking tool
• 1 x installation sheet
• 1 x front cover screw cap
Introduction
The DDI602 Outdoor Dual PIR Detector is an outdoor motion
detector and alarm trigger that uses two independent passive
infrared detectors plus a microwave sensor module.
All three sensors must trigger to cause the detector to signal
an alarm. The DDI602 uses triple detection technology to
