1 Ubbink FiltraClear – Pond Filter
Dear Customer, Dear Customer,
You have obtained a product from our FiltraClear pond fi lter range. With these instructions you have important information which is helpful for installation, set-up and operation, and You have obtained a product from our FiltraClear pond fi lter range. With these instructions you have important information which is helpful for installation, set-up and operation, and
maintenance of your FiltraClear pond fi lter.
Supplied
Contains/Supplied
Filter housing (25 l)
Chamber partition wall
Filter lid, large
Closing lid for UVC element
AlgClear UVC 2500 (5 W) specially for FiltraClear 4500
AlgClear UVC 70000 (9 W) specially for FiltraClear 8000
Bio cores with mesh (Chamber 1, below)
Filter sponge, black, 35 mm, ppi 10 (Chamber 1, top)
Zeolith with mesh (Chamber 2, below)
Filter sponge, blue, 35 mm, ppi 20 (Chamber 2, top)
Filter substrate with mesh (Chamber 3)
Ballvalve 1" (dirt drainage valve), nut and washer
Pond hose 40mm, black (for fi lter waste)
Hose clip 38-42 mm
Filter pump Powermax 1200 Fi
Filter pump Powermax 2200 Fi
Pond hose 19 mm, black (for fi lter supply)
Hose clip 20-23 mm
Instructions
Subject to technical alterations and substitution by articles having improved product properties.
Safety Safety
The instructions for use of the pumps used together with the FiltraClear Pond Filter and UVC device are to be strictly followed. The instructions for use of the pumps used together with the FiltraClear Pond Filter and UVC device are to be strictly followed. The instructions for use of the pumps used together with the FiltraClear Pond Filter and UVC device are to be strictly followed. The instructions for use of the pumps used together with the FiltraClear Pond Filter and UVC device are to be strictly followed.
To avoid overheating, a UVC device must be operated only if water is fl owing through the housing of the UVC device.
The UVC lamp should be checked by visual inspection through the inspection window provided for this purpose on the device. Never look directly into UV light, direct contact with UVC
rays can cause injury to eyes and/or skin!
