2.7 Save and Recall
Five group setups can be saved in memory. The contents of the setup file including:
 Independent/series/parallel mode
 Output voltage/current value
 Timer setup
Save setup
Operation steps:
1. Set the state that you required.
2. Short press "IP/Store" button and then long press "IP/Store" button to enter Store/Recall
interface.
3. Press direction button to move the cursor to "FILE CHOICE"
4. Select file store position (FILE1~FILE5) by revolving the multi-function knob.
5. Press direction button to move the cursor to "OPER CHOICE".
6. Move the cursor to "STORE" by revolving the multi-function knob, and then press it to
save the current setup.
Recall setup
Operation steps:
1. Short press "IP/Store" button and then long press "IP/Store" button to enter Store/Recall
interface.
2. Press direction button to move the cursor to "FILE CHOICE"
3. Select the required file by revolving the multi-function knob.
4. Press direction button to move the cursor to "OPER CHOICE".
5. Move the cursor to "RECALL" by revolving the multi-function knob, and then press it to
save the current setup.
Note: if you want to delete the file that has been saved, please go on with step 3 above,
select "DELETE" and then press it.
