Quick Installation Instructions
1
Install the Universal Wall Fitting
Installs i n m inutes o n p ools w ith a d edicated c leaner r eturn l ine a nd a t hreaded 1 -1/2" f emale p ipe f itting.
1. Turn on the filtration pump and flush out the plumbing line.Turn pump off.
2. Remove t he U WF f rom t he Q uick D isconnect a nd s crew t he U WF w ith t he b lue r estrictor d isk i nto t he
return opening.
3. Turn the Quick Disconnect clockwise into the UWF and pull away to secure.
Return Line
2
Adjust Feed Hose To Fit Pool Length
Measure t he d eepest p art o f t he p ool. C ut l eader h ose, f rom e nd t hat a ttaches t o f eed h ose, s o l ength i s e qual t o
the greatest depth of the pool.
Attach l eader h ose t o f eed h ose a nd c onnect h ose t o t he p ool w all a t t he r eturn l ine. E xtend h ose t o f arthest
point o f p ool. T he h ose e nd m ust b e w ithin 6 " – l onger o r s horter – o f t he f arthest p oint. S ee d otted c ircle.
Hose t oo l ong? S eparate h ose a t c enter s wivel. C ut e qual a mounts o f t he o verage f rom e ach 1 0-foot f eed
hose section.
Hose too short? Buy an additional feed hose section (part #9-100-3104), one swivel (part #D20) and two
hose nuts (part #D15) from an authorized Polaris dealer.
After adjusting hose, position hose floats as shown.
Return
Line
Restrictor Disc
Universal Wall Fitting
Filter Screen
Quick Disconnect
Pressure Relief Valve
Feed Hose Floats
1.5 to 3' apart
www.polarispool.com
Leader Hose
Length = Max. Depth
Center
Leader Hose Floats
Swivel
2-3' apart
