Pairing handheld transmitter & controller
The handheld transmitter is already paired in the factory and ready to
use. The PL-REM-200 can pair with up to 6 handheld transmitters. In
case a problem arises, the pairing process can be done manually:
Manual Pairing process:
Make sure the PL-REM-200 is connected to a power source.
1. Press the pairing button on the small circuit board, inside the con-
troller for at least 5 seconds.
--> The LED will start to blink fast
2. Within 25 seconds, press any button on the handheld transmitter.
--> If the transmitter is paired correctly, the LED will flash slowly for 5 times
--> If the PL-REM-200 pairing memory is full, the LED will flash 15 times.
This means 6 handheld devices have already been paired.
To unpair all handheld transmitters with the controller: Push the pair-
ing button for at least 5 seconds, then do nothing for at least 25 sec-
onds.
--> The pair memory will be erased - the red LED will flash 5x on/off.
Pairing button
Red LED
