Fastbind ELITE Handbuch Seite 12

6.1.2
a)
6.1.3
a)
c)
6.1.4
6.1.5
a)
rev. d5 Elite Multilang
© 2004.12 Maping Co
Secure the hardcover behind the sprung outer collar of the
paper guide.
a) Pull out the outer collar of the guide and slide the
cover edge under its rim.
b) The spring force of this collar will hold the hardcover
in place.
b)
Place the book block between the cover and clamp.
a, b) Adjust the block from side and top carefully to ensure
that it aligns correctly with the cover.
c) Push out air between pages using both hands.
d) Cover and papers properly aligned against back
support.
b)
d)
Hold papers against turntable with your left hand as shown in
the picture. Push the clamp forward and lock it by lifting the
clamp handle up with right hand.
Turn the table over (UP) by pushing the operating handle up.
a,b) Fold the cover back and the block is ready for adhesive
application.
b)
1 - 11
BINDING A HARDCOVER BOOK
