External Dimension Diagram

Weight
• 5.2 kg (11.5 lbs) [only metal fittings]
• 35.4 kg (78.0 lbs) [When used with a PDP-435XDE/435HDE/435FDE/435HDG display with speakers (PDP-S22-LR) attached.]
• 36.6 kg (80.7 lbs) [When used with a PDP-435XDE/435HDE/435FDE/435HDG display with speakers (PDP-S26-LR) attached.]
• 41.6 kg (91.7 lbs) [When used with a PDP-505XDE/505HDE/505HDG display with speakers (PDP-S21-LR) attached.]
• 42.9 kg (94.6 lbs) [When used with a PDP-505XDE/505HDE/505HDG display with speakers (PDP-S25-LR) attached.]
PDP-435XDE/435HDE/435FDE/435HDG display with speakers (PDP-S22-LR) attached
PDP-505XDE/505HDE/505HDG display with speakers (PDP-S21-LR) attached
PDP-435XDE/435HDE/435FDE/435HDG display with speakers (PDP-S26-LR) attached
PDP-505XDE/505HDE/505HDG display with speakers (PDP-S25-LR) attached
14
En
1120 (1270)
257 (332)
303
1118 (1268) [External dimension of a bottom speaker]
1288 (1438) [External dimension of a side speaker]
1312 (1462) [When doing a flush installation] 1350 (1500) [When doing an air installation]
303
257 (332)
1120 (1270)
496
455
407
292 (367)
355
Center line
(Screen center)
268
268
496
455
407
355
Center line
(Screen center)
571 292 (367)
Unit: mm
Dimensions in ( )
are the dimensions for
the 50 inch model
93 [Plasma display]
32 [Only metal fitting]
98
32 [Only metal fittings]
93
125
