Bort MASTER ECO Installationsanleitung Seite 11

• Use tongs or pliers to remove foreign objects from the
product.
• To reduce the risk of injury from particles that are thrown
out by the disposer, it is prohibited to use grinders
withoutnoise shielding screen (Fig.8.3). Place the plug in
the drain hole, as shown in Fig. 11.2 or 11.4.
Do not allow the following items to fall into the disposer:
shells, including oyster, caustic means for cleaning pipes or
similar chemical products, glass, porcelain or plastic, large
(hollow) bones, metal objects (bottle caps, cans, or kitchen
appliances), hot fat or other hot liquids.
• Replace worn noise glossy screen / installation gasket /
protective reflector if they are worn and are no longer able
to prevent waste or water.
• If the disposer is switched off, use a stopper to prevent
foreign objects in the grinding camera. Make sure that the
power of the disposer is disabled.
• Before pressing the reset button, cleaning the jam or
removing foreign objects from the shredding chamber,
make sure that the food is turned off.
• Keep hands and fingers out of the reach of disposer
chamber.
FIRE RISK:
To minimize the possibility of Do not store near fire
extinguishing articles such as rags, paper or aerosol cans.
Do not store or use gasoline or other flammable vapor-gas
mixtures and liquid near the disposer. Do not allow the
following camera products: paints, solvents, household
cleaning agents and chemicals, automotive liquids, plastic
packaging.
USER'S MANUAL
1. Use air switch (Fig. 11.1) for starting disposer.
2. Slowly lower food waste into the chamber and install the
filter grid in a vertical position (so that it flows through it
water) to reduce noise and possible throwing waste during
grinding (Fig.11.2).
3. After the grinding is completed, turn off the disposer and
let the water run for at least 15 s to flush the drain line.
SHOULD
• Grind food waste under pressure cold water not less than
6 liters / min.
• Grind solids, such as small bones and fruit residues, for
cleaning chopping chambers.
• Grind citrus fruits, melons, vegetables and coffee beans.
• After the grinding is finished, let the water run out at least
15 seconds to flush the drain pipeline.
• Unplug the product from the socket before removing the
seized rotor with a tool.
• Do not store any objects under the display to ensure
access to the button restart.
DO NOT
• Do not use hot water when grinding remains of products
(although hot water through the product between
grinding).
• Do not turn off the water or the product until the grinding
is completed, there is a noise of running engine and
running water.
• Do not grind large amounts of egg shells, fibrous
materials, for example corn husks, artichokes, etc., in order
to avoid possible clogging of the pipe.
• Grind only food.
• Do not use this appliance to grind hard materials, such as
glass and metal.
• Never pour fat, oil or fat in shell, as this will lead to
clogging drainage and sewerage systems.
• Do not fill the disposer chamber with a large amount of
cleaning vegetables. Instead, turn on the water first and
disposer and gradually lower it cleaning.
CLEANING THE DISPOSER CHAMBER
Over time, fat / food particles can accumulate in the
grinding chamber and protective reflector, causing an
unpleasant smell.
For cleaning grinding chamber and reflector:
1. Turn off the EQUIPMENT and disconnect it from the
mains.
2. Through the drain hole using a sponge for washing,
clean the bottom surfaces protective reflector and inner
upper edges of chopping chamber.
3. Place the plug in the drain hole and fill the sink with hot
water halfway.
4. Mix 60 ml of baking soda with water. Turn the product
on and remove the plug from the sink. washing of foreign
particles.
ELIMINATION OF JUMMING DISPOSER
If during the operation of the disposer motor stopped,
possibly jammed moving parts.
To eliminate jamming:
1. Turn off the power of the disposer and shut off the water.
2. Insert one end of the wrench into the center hole on
the bottom of the product for a self-contained removal of
stuck waste (Fig.11.5). Turn the wrench back and forth until
as long as he will not make one full turn. Take out wrench.
3. Remove foreign objects from the help ticks with long
handles. Give to the engine of the product cool for 3-5
minutes and press the red reset button on the bottom of
the disposer (Fig.11.6) (If the engine does not start, check
the protective shield for the presence of circuit breakers
and burnt out fuses).
SERVICE
If you need to perform maintenance or repair the product,
contact an authorized service center or to your dealer.
The warranty is canceled in the following cases:
- if the product was used with impairments requirements
of this manual
- in the presence of traces of the opening of the body of the
product for self-repair
For more details about the terms and conditions of the
warranty, see the warranty coupon
11
