7. Mini Bio Luxury boiler design (as a complete heating device)

60
7. Mini Bio Luxury boiler design (as a complete heating device)
7.1 Boiler design
Fig.: Mini Bio Luxury 12kW boiler design
Leader in pellet boilers
1. storage hopper cover
2. control panel
3. flexible hose
4. burner
5. ash pan tray
6. fuel sensor
7. storage hopper
8. boiler control system
9. STB safety temperature limiter
10. boiler door opening sensor
