Using Optional Accessories
CHANGING TO 8" RODS
If it is necessary to extend the Sled further away
from the Main Block, longer 8" Rods are available.
Fig. 11.1
Fig. 11.2
1. Loosen the four thumb
screws on the Sled and
Main Block (two per
piece).
2. Slide the 4" Rods out of
the Sled and Main Block
as shown in Fig. 11.1.
3. Insert the 8" Rods into
the sleeves of both the
Sled and the Main Block
(shown in Fig. 11.2).
Adjust the Sled to the
desired position and
tighten the four thumb
screws.

8" Rods

D
8" Rods
