Setting Up Your Loop
FRONT/BACK POSITION
Centered LitePad Loop
Slide the Loop so the front of the lens is flush with the Loop.
The camera lens should be positioned
just flush with the face of the LitePad
Loop. To adjust, loosen the the two
Sled [8] thumb screws and move the
entire Sled/Loop assembly until the
end of your lens is flush with the front
of the Loop. With longer lenses, it may
be necessary to use the optional 4" L-
Bracket and/or 8" Rods (page 16).
Loosen the thumb screws & slide the Loop forward and back.
Adjusting Loop Position
