Edirol DM-5 Bedienungsanleitung

Owner's Manual
Bedienungsanleitung
Mode d'emploi
Manuale d'uso
Manual del usuario
Thank you for purchasing the EDIROL Bi-Amp Monitor DM-5.
Before using this unit, carefully read the sections entitled: "IMPORTANT SAFETY
INSTRUCTIONS" (p. 2), "USING THE UNIT SAFELY" (p. 3-p. 4), and "IMPORTANT
NOTES" (p. 4-p. 5). These sections provide important information concerning the proper
operation of the unit. Additionally, in order to feel assured that you have gained a good
grasp of every feature provided by your new unit, this manual should be read in its
entirety. The manual should be saved and kept on hand as a convenient reference.
Main Features
In Pursuit of High Sound Quality
The DM-5 powered monitor uses a two-way, bi-amplifier design to achieve high sound quality.
The monitor features a 120-mm LF Driver and a 19-mm soft-dome HF Driver as speakers. The
amplification includes 30-watt and 20-watt amplifiers designed to achieve high sound quality.
Digital Input
In addition to XLR and TRS phone analog input, the DM-5 is provided with digital input connectors
(coaxial and optical) that support 96 kHz sample rate and 24-bit digital audio.
Digitally input signals are reproduced faithfully through 24-bit D/A conversion, thus preventing
noise or a drop in sound quality.
You can use the monitors with a wide variety of equipment and applications through selective use of
the analog and digital settings.
Contents
USING THE UNIT SAFELY................................................................3
IMPORTANT NOTES .........................................................................4
Function and Connection ................................................................6
Funktion und Anschlüsse................................................................8
Fonction et Connection..................................................................10
Funzionamento e Connessione.....................................................12
Función y conexión ........................................................................14
Reference ........................................................................................16
Copyright © 2001 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without the
written permission of ROLAND CORPORATION.
